Description
P-2240 Power Amplifier (CE-AU version)
Power Source | 220 – 240 V AC, or 24 – 30 V DC |
---|---|
Rated Output | 240 W |
Power Consumption | 238 W (EN60065), 520 W (AC operation at rated output), 15 A (DC operation at rated output) |
Frequency Response | 50 Hz – 20 kHz (±3 dB) |
Distortion | 1 % or less at 1 kHz, 1/3 rated power |
Input | Line in: 0 dB*, 10 kΩ, balanced, screw terminal, distance between barriers: 8.3 mm (0.33″) Speaker line in: 40 dB*, 330 kΩ, unbalanced, screw terminal, distance between barriers: 8.3 mm (0.33″) Power remote control: Make contact |
Output | Loop out: 0 dB*, 10 kΩ, balanced, screw terminal, distance between barriers: 8.3 mm (0.33″) Speaker out: Balanced (floating) High impedance: 42 Ω (100 V), 21 Ω (70 V) Low impedance: 4 Ω (31 V) |
S/N Ratio | 60 dB or more |
Tone Control | Bass: ±10 dB at 100 Hz Treble: ±10 dB at 10 kHz |
Ventilation | Fan cooling |
Finish | Panel: ABS resin, black Case: Steel plate, black |
Dimensions | 420 (W) × 100.9 (H) × 351.3 (D) mm (16.54″ × 3.97″ × 13.83″) |
Weight | 13.2 kg (29.1 lb) |
