A-3248D Digital Mixer Amplifier

A-3248D Digital Mixer Amplifier

A-3248D is a high performance yet cost-effective mixer power amplifier suited for broadcasting, paging, or background music in schools, offices, shops, houses of worship and large ballrooms.



সমগ্র দেশজুড়ে সার্ভিস

  • Genuine Products
  • One Year Warranty
Call for Update Price & Product Availability

01711-766062, 01711-461346, 01789-636363

Description

A-3248D Digital Mixer Amplifier

Power Source100 – 240 V AC, 50/60Hz
Rated Output480 W
Power Consumption99 W (AC operation at 1/8 maximum output without clip)
Frequency Response50 – 20,000 Hz
InputMIC 1: 1 mV (-60 dB*), 600 Ω, balanced, phone jack, selectable to RJ45
MIC 2-3: 1 mV (-60 dB*), 600 Ω, balanced, phone jack
MIC 4: 1 mV (-60 dB*) 600 Ω, balanced, phone jack, selectable to AUX 1
AUX 1: 100 mV (-20 dB*), 10 kΩ, unbalanced, RCA pin jack, selectable to MIC 4
AUX 2: 100 mV (-20 dB*), 10 kΩ, unbalanced, RCA pin jack
OutputSpeaker out: Speaker Output in screw type terminal
Direct line (selectable): 21 Ω (100 V) or 4 Ω
Rec out: 0 dB*, 600 Ω, unbalanced, RCA pin jack
Phantom PowerDC +21 V (MIC 1)
S/N RatioOver 60 dB
Total Harmonic DistortionUnder 1% at 1 kHz, 1/3 rated power
Tone ControlBass: ±10 dB at 100 Hz
Treble: ±10 dB at 10 kHz
MutingMIC 1: Mutes other input signals by 0-30 dB attenuation
IndicatorPower, Signal , Peak, Protect
VentilationFan Cooling
FinishPanel: ABS resin, black
Case: Steel plate, black
Dimensions420 (W) × 100.9 (H) × 357 (D) mm
Weight5.0 kg
