Description
A-2240 Mixer Power Amplifier (H version)
| Power Source | 220 – 240 V AC, or 24 – 30 V DC |
|---|---|
| Rated Output | 240 W |
| Power Consumption | 238 W (EN60065), 520 W (AC operation at rated output), 15 A (DC operation at rated output) |
| Frequency Response | 50 – 20,000 Hz (±3 dB) |
| Distortion | Under 1% at 1 kHz, 1/3 rated power |
| Input | Line in: 0 dB*, 10 kΩ, balanced, screw terminal 100 V line in: 40 dB*, 330 kΩ, unbalanced, screw terminal Power remote control: Make contact |
| Output | Loop out: 0 dB*, 10 kΩ, balanced, screw terminal Speaker out: Balanced (floating) High impedance: 42 Ω (100 V), 21 Ω (70 V) Low impedance: 4 Ω (31 V) |
| S/N Ratio | Over 60 dB |
| Tone Control | Bass: ±10 dB at 100 Hz Treble: ±10 dB at 10 kHz |
| Indicator | Power, signal, peak |
| Ventilation | Fan cooling |
| Finish | Panel: ABS resin, black Case: Steel plate, black |
| Dimensions | 420 (W) × 100.9 (H) × 351.3 (D) mm (16.54″ × 3.97″ × 13.83″) |
| Weight | 13.2 kg (29.1 lb) |
