A-3212DMZ Digital Mixer Amplifier with MP3 and Zones

A-3212DMZ Digital Mixer Amplifier with MP3 and Zones

A-3212DMZ is a high performance yet cost-effective mixer power amplifier equipped with MP3, Bluetooth function and Zone selection. Ideal for broadcasting, paging, or background music in schools, offices, shops, houses of worship and large ballrooms.

সমগ্র দেশজুড়ে সার্ভিস

  • Genuine Products
  • One Year Warranty
Call for Update Price & Product Availability

0185-3330344, 01789-636363, 02-48955951

Description

A-3212DMZ Digital Mixer Amplifier with MP3 and Zones

Power Source100 – 240 V AC, 50/60Hz
Rated Output120 W
Power Consumption44 W (AC operation at 1/8 maximum output without clip)
Frequency Response50 – 20,000 Hz
InputMIC 1: 1 mV (-60 dB*), 600 Ω, balanced, phone jack, selectable to RJ45
MIC 2-3: 1 mV (-60 dB*), 600 Ω, balanced, phone jack
MIC 4: 1 mV (-60 dB*) 600 Ω, balanced, phone jack, selectable to AUX 1
AUX 1: 100 mV (-20 dB*), 10 kΩ, unbalanced, RCA pin jack, selectable to MIC 4
AUX 2: 100 mV (-20 dB*), 10 kΩ, unbalanced, RCA pin jack
MP3: LED Display, Support USB, SD/MMC card (up to 32GB), Bluetooth, Radio FM, Record
OutputSpeaker out: Speaker Output in screw type terminal
Direct line (selectable): 83 Ω (100 V) or 4 Ω
Rec out: 0 dB*, 600 Ω, unbalanced, RCA pin jack
5-Zone Selector (all zones simultaneously selectable)
Phantom PowerDC +21 V (MIC 1)
S/N RatioOver 60 dB
Total Harmonic DistortionUnder 1% at 1 kHz, 1/3 rated power
Tone ControlBass: ±10 dB at 100 Hz
Treble: ±10 dB at 10 kHz
MutingMIC 1: Mutes other input signals by 0-30 dB attenuation
IndicatorPower, Signal , Peak, Protect
VentilationNatural Air Cooling
FinishPanel: ABS resin, black
Case: Steel plate, black
Dimensions420 (W) × 100.9 (H) × 357 (D) mm
Weight4.6 kg
AccessoryRemovable terminal plug (2pin) x 5, Antenna FM radio (1m) x 1
